系统 |
IC2K & DSS |
 |
。超高性能塔式、机架式及便携式PC服务器，可定制配置 |
。多达20个独立的PCI总线插口，专为高速数据传输设计 |
。支持SIGNATEC数据存储系统DSS，最高1GB/s数据传输率 |
。最高32TB存储容量 |
。集成SIGNATEC系统软件 |
|
DR系列高速多通道信号采样记录仪 |
 |
。高达250MB/s，350MB/s，700MB/s的采样速率能力 |
。高达18TB的存储深度 |
。可扩展采样速率以及存储容量 |
。多通道同步采样 |
。8位，14位，16位分辨率 |
|
 |
 |
| |
| SIG便携式数据分析仪 |
SIG-PRG SIG-PWR SIG-PWG |
 |
| The SIG-PRG is a portable high-speed data acquisition and waveform generation Test & Measurement system that offers the following embedded A/D features: |
| ● 160 MHz Sample Rate |
| ● 16-bit A/D Resolution |
| ● Dual Channels |
| ● Bandwidth from DC-700 MHz |
| ● 512 MB Onboard Memor |
| |
| Embedded within the same portable chassis, the Sig-PRG offers the following D/A features |
| ● 4 16-bit DAC Outputs at 1000 MSPS |
| ● 512 Megabytes DDR RAM |
| ● Wide Selection of Output Filters |
| ● Interpolation at 2, 4, or 8x Data Rate |
| ● Digital Quadrature Modulator |
| |
| The SIG-PWR is Signatec’s portable high-speed data acquisition Test & Measurement system that offers the following embedded A/D features: |
| ● 160 MHz Sample Rate |
| ● 16-bit A/D Resolution |
| ● 4 Channels |
| ● Bandwidth from DC-700 MHz |
| ● 1024 MB Onboard Memory |
| |
| The SIG-PWG is Signatec’s portable high-speed arbitrary waveform generation Test & Measurement system that offers the following embedded D/A features: |
| ● 8 16-bit DAC Outputs at 1000 MSPS |
| ● 1024 Megabytes DDR RAM |
| ● Wide Selection of Output Filters |
| ● Interpolation at 2, 4, or 8x Data Rate |
| ● Digital Quadrature Modulator |
 |
| |
| |
| |
| |
